Step 1 is intended to check your schematic for design rule violations that keep your schematic from being synchronized with your PCB layout. Step 2: Use the Schematic Editor to Import Design Data to a PCB Step 1: Preparing to Synchronize the Design The process for how to convert a schematic to a PCB layout in Altium Designer follows three simple steps: How to Convert Schematic to PCB Layout in Altium Designer Creating a PCB layout from a PCB schematic doesn’t have to be difficult, and Altium Designer can serve as your all-in-one schematic to PCB converter. This simple little design probably won’t be anything like the schematics that you are working on, but the basic steps of data transfer from schematic to circuit board will be the same. We’ll take a look here at a very simple PCB schematic and see what needs to be done to synchronize it with a brand new PCB design. Whatever the reason, you are ready to start working on the board side of PCB design, but you’re not sure how to create it from a PCB schematic in Altium Designer.įortunately, the next step in Altium Designer is very straightforward. Maybe your regular layout resources aren’t available, or perhaps you want to try to do your first layout yourself.
The circuitry is defined and you are ready to go to PCB layout.
The software will cross probe to the item on the target document.You’ve done your usual excellent job of putting together the PCB schematic. Position the crosshair on any component or net then click. You can use this tool by choosing Tools > Cross Probe from the main menus. the PCB document and the schematic document are open on different monitors. The best way to use this tool is by working on two monitors, i.e. Altium Designer has a Cross Probe tool that helps you to find components on the PCB by clicking on the component in the schematic and vice versa.
Some components must be placed close to each other in order for them to work correctly. Additionally, good placement of passive components will allow forming a proper decoupling and device configuration.Ĭorrect component placement requires attention to the schematic. Good placement of high-speed ICs allows your interfaces to run at maximum speed without any errors. The correct placement of the power components will create good conditions for the correct function of the power-distribution network, help to avoid unnecessary voltage drop-downs, and reduce power ICs noise on high-speed ICs. The correct placement of the connectors can be organized to ensure the correct ergonomics of the device. It is at this stage that a significant part of possible future problems can be solved. Competent placement of components has a huge impact on the quality of board routing and behavior. Now we've come to one of the most interesting parts of the PCB design process - component placement.
